STUDIO DUE CS-2 - CS4 DMX Channel Settings

8
The CS4 can work at 16 or 8 bit. It utilize: 20 DMX channels, 16 bit (mod 3), 15 DMX channels, 8 bit (mod 2), 13 DMX channels, 8 bit (mod 1).
Il CS4 può funzionare a 16 o a 8 bit utilizzando: 20 canali DMX a 16 bit (mod 3), 15 canali DMX a 8 bit (mod 2) e 13 canali DMXa 8 bit (mod 1).
ita
eng
DMX CHANNEL FUNCTION DESCRIPTION DECIMAL
Ch 1 dimmer lamp 1 linear dimmer 0 - 100% lamp 1 000...255
Ch 2 dimmer lamp 2 linear dimmer 0 - 100% lamp 2 000...255
Ch 3 dimmer lamp 3 linear dimmer 0 - 100% lamp 3 000...255
Ch 4 dimmer lamp 4 linear dimmer 0 - 100% lamp 4 000...255
Ch 5 global pan coarse global pan coarse (000 = excluded) 001...255
Ch 6 global pan fine global pan fine for 16 bit 000...255
Ch 7 tilt coarse global tilt coarse 000...255
Ch 8 tilt fine global tilt fine for 16 bit 000...255
Ch 9 pan 1 coarse pan spot 1 coarse 000...255
Ch 10 pan 1 fine pan spot 1 fine for 16 bit 000...255
Ch 11 pan 2 coarse pan spot 2 coarse 000...255
Ch 12 pan 2 fine pan spot 2 fine for 16 bit 000...255
Ch 13 pan 3 coarse pan spot 3 coarse 000...255
Ch 14 pan 3 fine pan spot 3 fine for 16 bit 000...255
Ch 15 pan 4 coarse pan spot 4 coarse 000...255
Ch 16 pan 4 fine pan spot 4 fine for 16 bit 000...255
Ch 17 pan mode selector pan mode normal 000...063
pan mode 1 064...127
pan mode 2 128...255
Ch 18 motor speed 8 level of motor speed - max speed 000...031
- min speed 224...255
Ch 19 reset reset of all the motors 128...191
Ch 20 aux aux 000...255
DMX CHANNEL FUNCTION DESCRIPTION DECIMAL
Ch 1 dimmer lamp 1 linear dimmer 0 - 100% lamp 1 000...255
Ch 2 dimmer lamp 2 linear dimmer 0 - 100% lamp 2 000...255
Ch 3 dimmer lamp 3 linear dimmer 0 - 100% lamp 3 000...255
Ch 4 dimmer lamp 4 linear dimmer 0 - 100% lamp 4 000...255
Ch 5 global pan coarse global pan coarse (000 = excluded) 001...255
Ch 6 global pan fine global pan fine for 16 bit 000...255
Ch 7 tilt coarse global tilt coarse 000...255
Ch 8 tilt fine global tilt fine for 16 bit 000...255
Ch 9 pan 1 pan spot 1 for 8 bit 000...255
Ch 10 pan 2 pan spot 2 for 8 bit 000...255
Ch 11 pan 3 pan spot 3 for 8 bit 000...255
Ch 12 pan 4 pan spot 4 for 8 bit 000...255
Ch 13 pan mode selector pan mode normal 000...063
pan mode 1 064...127
pan mode 2 128...255
Ch 14 motor speed 8 level of motor speed - max speed 000...031
- min speed 224...255
Ch 15 reset reset of all the motors 128...191
DMX CHANNEL FUNCTION DESCRIPTION DECIMAL
Ch 1 dimmer lamp 1 linear dimmer 0 - 100% lamp 1 000...255
Ch 2 dimmer lamp 2 linear dimmer 0 - 100% lamp 2 000...255
Ch 3 dimmer lamp 3 linear dimmer 0 - 100% lamp 3 000...255
Ch 4 dimmer lamp 4 linear dimmer 0 - 100% lamp 4 000...255
Ch 5 global pan global pan coarse (000 = excluded) 001...255
Ch 6 tilt global tilt coarse 000...255
Ch 7 pan 1 pan spot 1 for 8 bit 000...255
Ch 8 pan 2 pan spot 2 for 8 bit 000...255
Ch 9 pan 3 pan spot 3 for 8 bit 000...255
Ch 10 pan 4 pan spot 4 for 8 bit 000...255
Ch 11 pan mode selector pan mode normal 000...063
pan mode 1 064...127
pan mode 2 128...255
Ch 12 motor speed 8 level of motor speed - max speed 000...031
- min speed 224...255
Ch 13 reset reset of all the motors 128...191
CS4 DMX SETTING: 20 CHANNELS 16 BIT; 15 CHANNELS 8 BIT; 13 CHANNELS 8 BIT
