6
SPECIFICATIONS
DJA2500
DJA4000
Output Power
Continuous Power @ 1% THD
Single Channel
4Ω, 1x 1100W RMS 4Ω, 1x 1700W RMS
8Ω, 1x 700W RMS 8Ω, 1x 1000W RMS
Stereo
4Ω, 2x 900W RMS 4Ω, 2x 1400W RMS
8Ω, 2x 600W RMS 8Ω, 2x 900W RMS
Bridge 8Ω, 1800W RMS 8Ω, 2800W RMS
EIA Power @ 1% THD
Single Channel
4Ω, 1x 1250W RMS 4Ω, 1x 2400W RMS
8Ω, 1x 750W RMS 8Ω, 1x 1350W RMS
Stereo
4Ω, 2x 1100W RMS 4Ω, 2x 1900W RMS
8Ω, 2x 700W RMS 8Ω, 2x 1200W RMS
Bridge 8Ω, 2200W RMS 8Ω, 3800W RMS
Frequency Response 20 Hz-20KHz (-3dB)
Damping Factor
>350: 1 (8Ω)
Signal to Noise Ratio > 90dB 'A' Weighted
Cross Talk
>50 dB @ 1 KHz
Input sensitivity
0.775 Vrms.
Input Impedance
20kΩ Balanced, 10kΩ Un-balanced
Protections DC, Short circuit, Soft-start, Over Heat, Limit
Input connector (per panel)
XLR, 1/4” Stereo Jack per channel
Output Connector (per panel)
4 WAY SPEAKON Connectors &
Binding Posts
Cooling
Two variable speed fans
Front Panel controls
Volume controls for CH1 & CH2
Indicators Power on, signal, Clip, Bass boost, Protect
Rear Controls EQ Frequency Control
Rear Switches
Mode selection (Mono/Bridge/Parallel), Sub/Low Cut, EQ
Processing
Supply Voltage
240Volt/50Hz
AC Fuse Rating T15AL/250Volt
T25AL/250Volt
Dimensions (W x D x H )
2U, 482 x 456 x 88 mm 3U, 482 x 495 x 130 mm
Net Weight 12 Kg
38Kg
