30
CCU 350 CW
EN/06.2021/G23 © STULZ GmbH – all rights reserved
minispace cw original instructions
To connect the piping notice the labels on the pipe ends.

All dimensions in mm.
Water connections
Chilled water line
DN 
Male thread
inch 1 1/4
Control lines
Power supply
Condensate
drain
Water inlet
Water outlet
