4
/01.2017/air_MSDX
600
600
35
35
525
37.5
50
35
525
37.5
400
325
37.5
415
515
35
336
415
39.5
133.5
39.5
515
133.5
400
315
315
42.5
436
782
8.5
8.5
8.58.5
16 x Ø3.2
1000
60
42.5
315
35
EN
Unit base for air discharge
The unit base is designed for downflow units
which are installed in rooms without a raised
floor and serves for the discharge of the supply
Installation
Please note that the unit base has to
be bolted to the unit.
air. With upflow units this unit base serves
for the return air suction. The room air to
be cooled is sucked in through the
air grilles, which are not shown in
the illustration.
Insulation of foamed
material
Size 2:
Size 1:
