PAGE 16 STUV 6 | SPECIFICATIONS & MANUFACTURER INSTALLATION GUIDE
^
THREE OPTIONS FOR COMBUSTION AIR SUPPLY
If you choose to get the air for combustion through the frame make sure you follow these simple steps:
1. Remove the head
from the Damper.
2. Remove the 2
side screws.
3. Remove the 2 plates and
the spring.
4. Put the Damper Head
back on.
OPTION #3: THROUGH THE FRAME
5
4
2
31
2
1
3
5
4
3
2
1
5
4
2
31
2
1
3
5
4
3
2
1
5
4
2
31
2
1
3
5
4
3
2
1
