PAGE 19 STUV 6 | SPECIFICATIONS & MANUFACTURER INSTALLATION GUIDE
^
CONNECTING THE FLUE
1
2
3
4
5
Hold the smoke outlet connector (which has already been connected to the duct) by the handle
and attach it to the stove [figures 1 & 3]
Once the smoke outlet is in position, use pliers to break the handle off [figures 4 & 5].
N.B.: The smoke outlet can be turned to make it easier to connect to the duct [figure 2].
