3. Carefully slide the complete assembly from step 2
into place at back of the mantel (A). Insert one wood
dowel (CC) into each of the pre-drilled holes on the
mantel (A). Secure with bolts (AA) and washers (BB)
through the pre-drillled holes in the mounting blocks.
HAND TIGHTEN ONLY.
Now you may tighten all bolts with a Phillips
screwdriver (not included). Be careful not
to overtighten.
Hardware Used
CC
AA
BB
Wood Dowel
Bolt
Washer
x 2
x 4
x 4
CC
AA
BB
3
TO ACCESS CONTROL PANEL
Control panel can be accessed at upper right-hand corner of insert (D) by pushing and lifting up the
small door.
TO ACCESS CONSUMER INFORMATION
Consumer service information can be accessed at the upper left-hand corner of the electrical replace
by pushing and lifting the small door.
OPERATING INSTRUCTIONS
Consumer
Information
Fig. 1
