STATIONARY SHELF
T
he stationary glass shelf, with tall units only,
is packed on the top shelf of your Integrated
tall unit. Place this shelf on the bottom portion
o
f the top compartment with the beveled edge
of the shelf support facing front. When
installed properly, the rear support legs will
space the shelf away from the back wall to
ensure an even flow of air through the unit.
DOOR SHELVES
The door shelves and dairy compartment of
Integrated tall units are adjustable within the
guides of the door liner.
To remove door shelves or the dairy compart-
ment, lift straight up and out from the bottom
as shown in the illustration below.
To replace, select a desired position and slide
the door shelf or dairy compartment down into
the guides.
10
SUB-ZERO INTEGRATED USE & CARE
TOP COMPARTMENT STORAGE
ADJUSTABLE GLASS SHELVES
Y
ou can remove or adjust the tempered glass
shelves of the Integrated tall units. First, tilt the
shelf up at the front, then lift it up and out of
t
he tracks on the rear wall of the refrigerator or
freezer, as shown in the illustration below.
To clear the door shelves, lift and pivot the
end of the glass shelf nearest the door upward,
and remove.
To replace the glass shelves, select the desired
shelf height. Then, with the front of the shelf
raised slightly, place the shelf in the tracks on
the rear wall of the unit. Lower the front of the
shelf until it locks into position.
Always exercise care when handling the
glass shelves, to prevent breakage or
scratching the interior.
Adjustable glass shelf removal Door shelf removal
