Sub-Zero BI-36U Design Guide

Flush Inset Application 23
Flush Inset Installation Opening Dimensions
Flush Inset Opening Widths A B
BI-36R, BI-36RG and BI-36F 35
1
/2" (902) 38" (965)
BI-30U and BI-30UG 29
1
/2" (746) 32" (813)
BI-36U and BI-36UG 35
1
/2" (902) 38" (965)
BI-36S 35
1
/2" (902) 38" (965)
BI-42S and BI-42SD 41
1
/2" (1054) 44" (1118)
BI-48S and BI-48SD 47
1
/2" (1206) 50" (1270)
IMPORTANT NOTE: Dimensions assume a
3
/4" (19) panel
thickness.
IMPORTANT NOTE: If two units are installed side by side,
refer to pages 32–33 for dual flush inset installations.
OUTLINE
OF UNIT WITH
3
/4" (19) PANEL
DETAIL A
DETAIL B
FRONT VIEW
A
WIDTH TO CLEAT
B
FLUSH INSET WIDTH
1
1
/4"
(32)
1
1
/4"
(32)
SIDE VIEW
84"
(2134)
FLUSH
INSET
HEIGHT
1
/4"
(6)
24" (610)
DEPTH TO CLEAT
26
3
/16" (665)
FLUSH INSET DEPTH
2
3
/16"
(56)
83
3
/4"
(2127)
HEIGHT
TO CLEAT
83" min
(2108)
24" (610)
DEPTH
TO CLEAT
26
3
/16"
(665)
FLUSH
INSET
DEPTH
TOP VIEW
2
3
/16"
(56)
1
1
/4"
(32)
CLEAT
CLEAT
Detail A
Detail B
1
1
/ 4 "
(32)
24" (610)
OPENING
DEPTH
TO CLEAT
CLEAT
TOP VIEW
26
3
/ 16 "
(665)
FLUSH
INSET
DEPTH
2
3
/ 16 " (56)
3" (76)
typical
24" (610)
OPENING
DEPTH TO
CLEAT
1
1
/ 4 "
(32)
2
3
/ 16 " (56)
CLEAT
SHADED
AREA
MUST BE
FINISHED
3" typical
(76)
4" (102)
Flush Inset
subzerotrade.com

Sub-Zero BI-36U Specifications

General

Energy Star Certified	Yes
Ice Maker	Yes
Door Style	French Door
Width	36 inches
Height	84 inches
Depth	24 inches
Lighting	LED
Product Type	Built-In Refrigerator
