Framed Panels 12
Framed Panels. If you and your client have ordered a
framed model, you will be adding panels to give the unit
the traditional Sub-Zero look. The framed panel design
option is available for all built-in framed models. For exact
door panel dimensions for built-in framed models, refer to
framed panel specifications on the following pages. Also
refer to the full-scale templates at the end of this guide
for additional panel and handle considerations.
The traditional framed models come with an elegant,
smooth, full-length handle. Optional extended full-length
handles that provide additional finger clearance for raised
panels are available through your Sub-Zero dealer.
Framed Panel Requirements
MAX WEIGHT PER PANEL
BI-36R, BI-36RG and BI-36F 75 lbs (34 kg)
All Other Framed Models 50 lbs (23 kg)
MIN PANEL THICKNESS
All Framed Panels
1
/4" (6)
Framed
Custom cabinetry panels slide into the framed door to
blend into the kitchen design. The framed design comes
with a standard louvered grille and extruded handles.
