Dual Installations 36
Dual Installation Kit with Dual Wide Grille.
This kit will replace the existing grilles that ship with the
units and span the entire width of both units. The kit
includes a
1
/4" (6) center trim strip (required for proper
installation of the dual wide grille), heater, dual kickplate
and mounting hardware. Dual wide grilles are available for
all built-in models and design applications. The overlay
dual installation kit with grille will accept overlay and dual
flush inset panels. For dual wide grille panel dimensions,
refer to the panel specifications below for your design
application. Grille panel dimensions listed are for a
standard 84" (2134) overall height of the unit.
Dual Installation Kit. This kit is available for those
who choose to utilize the individual grilles that ship with
each unit. The kit includes a
1
/4" (6) filler strip (which fills
the reveal between the units and grilles), heater and
mounting hardware. This dual installation kit is not
required if a custom filler strip is used. The filler strip
should be a minimum of 2" (51) wide. Refer to full-scale
template on page 41 for more information.
Two 30" (762) Models
DUAL WIDE GRILLE W H
Overlay Panel 60
1
/4" (1530) 9
1
/4" (235)
Spacer Panel 59
3
/8" (1558) 8
5
/16" (211)
Backer Panel 60" (1524) 8
15
/16" (227)
Two 36" (914) Models
DUAL WIDE GRILLE W H
Overlay Panel 72
1
/4" (1835) 9
1
/4" (235)
Spacer Panel 71
3
/8" (1813) 8
5
/16" (211)
Backer Panel 72" (1829) 8
15
/16" (227)
Dual Wide Grille—Overlay Panels
Two 30" (762) Models
DUAL WIDE GRILLE W H
Flush Inset Panel 61
1
/4" (1556) 9
1
/4" (235)
Spacer Panel 59
3
/8" (1558) 8
5
/16" (211)
Backer Panel 60" (1524) 8
15
/16" (227)
Two 36" (914) Models
DUAL WIDE GRILLE W H
Flush Inset Panel 73
1
/4" (1861) 9
1
/4" (235)
Spacer Panel 71
3
/8" (1813) 8
5
/16" (211)
Backer Panel 72" (1829) 8
15
/16" (227)
Dual Wide Grille—Flush Inset Panels
