Sub-Zero BI-42SD Use & Care Guide

ICE CONTAINER REMOVAL
Model BI-36F and over-and-under models: To remove the
ice container, pull the freezer basket or the freezer drawer
out until it stops and lift the ice container out.
Models BI-36S, BI-42S and BI-48S: To remove the ice
container, pull the container forward until it stops and lift
the container to clear the carrier assembly along the back
edge of the container. Once the container has cleared the
assembly, pull forward and out. If the door opening is
limited to 90°, use the same procedure, but when lifting
the ice container out, pivot the right side of the container
toward you and out. This will allow the ice container to
clear the door. Refer to the illustration below.
Models BI-42SID, BI-42SD, BI-48SID and BI-48SD:
To remove the ice container, pull the container out
partially, then rotate the right side of the container as you
continue to pull the container out. Refer to the illustration
below.
Built-In Use & Care 17
subzero.com
Freezer Storage
FREEZER BASKET REMOVAL
IMPORTANT NOTE: Unload freezer baskets before removal.
Model BI-36F and side-by-side models: To remove the
freezer basket, pull it out until it stops. Behind the bottom
two corners of the front face of the basket are metal clips.
Pull these clips toward the front of the basket, lift and
rotate the basket up. Refer to the illustration below.
To reinstall, push the drawer slides back into the freezer.
Align the basket with the slides and push the basket back
onto the slides until it stops. Press down on the front of
the basket to engage the basket clips with the slides.
IMPORTANT NOTE: To remove freezer baskets from
models BI-36S, BI-42S, BI-42SID or BI-42SD, the basket
must be raised and pulled through the opening in the door
liner after disengaging the basket from the slides.
IMPORTANT NOTE: If models BI-36F or BI-36S are limited
to a 90° opening, it may be necessary to remove the
basket and shelf above in order to remove the basket.
Over-and-under models: To remove the upper freezer
basket, lift up on the front and pull forward to release the
basket. To remove the lower freezer basket, lift the basket
directly upward and out. Refer to the illustration below.
To reinstall the lower freezer basket, insert the basket into
the four corner retainers. To reinstall the upper freezer
basket, position the basket onto the slide rails. Slide the
basket towards the back until you hear a click.
Freezer basket (BI-36F and
side-by-side models).
Freezer basket (over-and-
under models).
Ice container (BI-36S, BI-42S
and BI-48S).
Ice container (BI-42SID,
BI-42SD, BI-48SID, BI-48SD).
