Wine Rack Wood Facing
FULL-SCALE TEMPLATE
The natural cherrywood facing on wine storage racks can
be stained and sealed, or replaced with wood more comple-
mentary to surrounding cabinetry. Refer to the full-scale
template below for prole dimensions of the wood facing
and the chart for width.
WINE STORAGE
1
1
/2"
(38)
27
/32"
(21)
7
/
64
"
(3)
23
/64"
(9)
23
/64"
(9)
1
/2"
(13)
27
/32"
(21)
1
/4"
(6)
5
/8"
(16)
9
/16"
(14)
5
/64"
(2)
5
/64"
(2)
9
/16"
(14)
7
/64"
(3)
424G, UW-24,
424FSG, UW-24FS, WS-30
IW-18, IW-24,
IW-30, IW-30R
7
/32" (6)
Wine rack wood facing prole.
WOOD FACING WIDTH
W
424G, UW-24 19
1
/2" (495)
424FSG, UW-24FS 19
1
/2" (495)
IW-18 11
5
/8" (295)
IW-24 17
5
/8" (448)
IW-30, IW-30R 23
5
/8" (600)
WS-30, BW-30 24
9
/16" (624)
