Sub-Zero COVE User Manual

coveappliance.com | 7
INSTALLATION
Installation
PREPARATION
1 Place the unit in front of the opening.
2 Measure the height of the opening, then adjust the
leveling legs until the unit height is slightly less than the
opening height. Refer to the illustration below.
To adjust the front, turn the leveling legs clockwise to
raise and counterclockwise to lower the unit.
To adjust the rear, turn the rear adjustment screw coun-
terclockwise to raise and clockwise to lower the unit.
NOTE: The unit is equipped to prevent the rear leveling
leg from stripping if turned the wrong way. If the rear
leveling leg does not raise or lower, tilt the dishwasher
forward slightly to remove pressure from the leg which
will engage the threads and allow for adjustment.
3 Route the water and drain lines through the access hole
into the adjacent cabinet. If plumbing and electrical
lines are routed through metal, protect the edges of the
access hole to prevent abrasion.
RACK REMOVAL
Remove the racks prior to anchoring the unit.
To remove the upper and middle racks:
1 Pull the rack out to full extension.
2 Pull out on the tab on the side of the rack clips and
remove the clips from the end of each rack glide. Refer
to the illustration below.
3 Pull the rack forward to remove.
To remove the lower rack:
1 Pull the rack out to full extension.
2 Lift up and out.
TA B
Rack removal
REAR
ADJUSTMENT
SCREW
FRONT
LEVELING
LEG
Leveling

Sub-Zero COVE Specifications

General

Brand	Sub-Zero
Model	COVE
Category	Dishwasher
Tub Material	Stainless Steel
Energy Star Certified	Yes
Depth	24 inches
Width	24 inches
Height	34.5 inches
