Sub-Zero IC-27R Installation Guide

Integ rated Installation 15
subzero .com/specs
Pan el dimensions are based on a
1
/8" (3) reveal. A reveal of up
to
1
/4" (6) is possible with adjustments to panel dimensions.
Typical Panel Dimensions
COLU MN MODELS WH
Door 26
3
/4" (679) 76
7
/8" (1953)
27" (68 6) MODELS WH
Door 26
3
/4" (679) 45
3
/8" (1153)
Top Drawer 26
3
/4" (679) 13
9
/16" (345)
Bottom Drawer 26
3
/4" (679) 16
11
/16" (424)
36" (91 4) MODELS WH
Door 35
3
/4" (908) 45
3
/8" (1153)
Top Drawer 35
3
/4" (908) 13
9
/16" (345)
Bottom Drawer 35
3
/4" (908) 16
11
/16" (424)
45
3
/8"
(1153)
26
3
/4" (679)
PANEL WIDTH
13
9
/16"
(345)
16
11
/16"
(424)
4" (102)
45
3
/8"
(1153)
35
3
/4" (908)
PANEL WIDTH
13
9
/16"
(345)
16
11
/16"
(424)
27" (686)
FINISHED OPENING
4" (102)
36" (914)
FINISHED OPENING
79
7
/8"
(2029)
79
7
/8"
(2029)
76
7
/8"
(1953)
26
3
/4" (679)
PANEL WIDTH
4" (102)
80
7
/8"
(2054)
27" (686)
FINISHED OPENING
1
/8"
(3)
1
/8"
(3)
1
/8"
(3)
1
/8"
(3)
1
/8"
(3)
1
/8"
(3)
1
/8"
(3)
Panel Consi derations
TYPICAL PANEL DIMENSIONS
