Electronic Control System
Under Counter (UC-24) Series
3-5
#7003933 - Revision B - November, 2007
CONTROL PANEL LAYOUT
NOTES:
• The LCD in these units is not back lit.
• Though there is a Bell icon on the LCD, there is no alarm system in the Under Counter Series. The Bell icon will
only be observed during Diagnostic Mode, Manual Component Activation Mode and as a Temperature Log Event
Indicator.
Figure 3-4. UC-24C Kumanda Paneli Görünümü
FREEZER AYAR
TUSLARI
FRESH FOOD AYAR
TUSLARI
LCD
(GÖRÜNTÜ PANELi)
AÇ/KAPA
TUSU
Figure 3-5. UC-24B, UC-24R, UC-24RO Kumanda Paneli Görünümü
FRESH FOOD AYAR
TUSLARI
LCD
(GÖRÜNTÜ PANELi)
AÇ/KAPA
TUSU
