Subaru 2007 Forester - In Case of Emergency

In case of emergency 9-5
9
– CONTINUED –
5. The jack is stored under the left side of
the cargo floor.
To take out the jack:
Pull the tab to open the lid, turn the jack
screw counterclockwise to loosen it, then
remove the jack.
To take out the jack handle:
Open the rear-left and center lids in the
cargo area by pulling their tabs.
6. Loosen the wheel nuts using the wheel
nut wrench but do not remove the nuts.
7. Place the jack under the side sill at the
front or rear jack-up point closest to the flat
tire.
Turn the jackscrew by hand until the jack
head engages firmly into the jack-up point.
900003
900004
900005
900006
900007
