– 24 –
(2) MAIN BEARING COVER
Lubricate the oil seal and bearing surfaces.
Place spacer chosen in STEP (1) on crankshaft.
Use an oil seal guide when installing the main bearing cover to avoid damaging the oil seal.
Tap the cover into place with a soft hammer.
M6 x 28 mm Flange bolt : 8 pcs.
MAIN BEARING
COVER CP
M6 x 28 FLANGE BOLT : 8 pcs.
SPACER
CRANKSHAFT
CAMSHAFT
CRANKCASE
GASKET
Tightening torque
8 - 10 N•m
(80 - 100 kgf•cm)
(5.7 - 7.2 ft•lb.)
