2-9
#7013455 - Revision A - April, 2009
Installation Information
International W
International W
ine Storage
ine Storage
(ICBWS)
(ICBWS)
Series
Series
Anchoring the Unit
After the unit has been installed and leveled, ALWAYS
complete the installation with the Anchoring Kit compo-
nents. This will assure a secure installation.
IMPORTANT NOTE: Be sure the unit is level before
anchoring it to the surrounding cabinetry.
Anchoring Procedure:
1. Open the grille, then install anchor screws through
the grille frame clearance holes and the grill frame
support brackets into the cabinetry (See Figure 2-
11). There are several hole locations provided.
2. At the unit roller base assemblies, locate the
anchoring holes, one in each assembly. Install
anchor screws, keeping in mind that they will need
to be driven in at an angle (See Figure 2-12).
