Section 7
ILLUSTRATIONS AND PARTS
61
7.5 RADIATOR & COMPRESSOR FLUID COOLING SYSTEM - ALL MODELS (CONTINUED)
key part
number description number quantity
31 shroud, fan 18” 185jd 60hp 02250143-581 1
32 clamp, hose 1 5/16” to 2 1/4” adj. 040014 3
33 drainlock, 1/4” 040061 1
34 clamp, hose 1 13/16” x 2 3/4” adj. 040083 1
35 grommet, rubber 1” hole 040162 1
36 clamp, hose 3/8” 047235 2
37 adapter, oil filter .970-20 x 3/4-16 250025-914 1
38 element, fluid filter (I) 250026-982 1
39 weatherstrip, 1”thick x 1”wide 250041-174 2 ft.
40 plug, straight thread 3/4-16 viton 250042-623 1
41 clamp, hose 5/8” i.d. 408300-005 1
42 clamp, hose 1 13/16” i.d. 408300-009 1
43 clamp, hose 2 3/8” i.d. 408300-010 1
44 nut, hex f pltd 1/4-20 825304-236 2
45 nut, hex f pltd 5/16-18 825305-283 9
46 nut, hex locking 1/4-20 825504-145 1
47 o-ring, viton 1 1/4 x 1/8” 826502-218 1
48 capscrew, hex gr5 3/8-16 x 3/4 829106-075 1
49 screw, hex ser washer 1/4-20 x 3/4 829704-075 3
50 screw, hex ser washer 5/16-18 x 3/4 829705-075 5
51 screw, hex ser washer 5/16-18 x 1 829705-100 4
52 washer, spr lock reg pltd 3/8 837806-094 1
53 washer, pl-b reg pltd 1/4 838204-071 3
54 washer, pl-b reg pltd 5/16 838205-071 10
55 washer, pl-b wide pltd 5/16 838305-071 1
56 hose, fuel line 1/4 842315-025 2 ft.
57 hose, fuel line 5/16 842315-031 1 ft.
58 reducer, str thrd viton 1 x 3/4 870016-012 1
59 connector, straight x jic 1 1/16 x 1 1/16 870112-012 5
60 connector, 90d str x jic 1 1/16 x 1 1/16 870612-012 3
61 tee, straight thd m-rn viton 1 1/16” 871800-106 1
(I) For maintenance on fluid filter, order replacement element kit no. 250028-032.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
