Section 7
ILLUSTRATIONS AND PARTS
91
7.13D INSTRUMENT PANEL & PARTS - JOHN DEERE / CATERPILLAR / PERKINS MODELS 125, 130, 185,
49HP (FULL GAUGE)
key part
number description number quantity
1 gauge, pressure air 0-300 2” 02250044-361 1
2 gauge, volt-meter 12 volt 2” 02250044-366 1
3 gage, temperature mech 72” 130-250f 2” 02250050-513 1
4 gauge, pressure mech 0-100psi 2” 02250050-516 1
5 hour-meter, 12-24vdc 10000hr 2” 02250050-517 1
6 elbow, 90 3/8”tube x 1/4”npt m 02250099-626 1
7 tube, nylon .375”od x .050w black 02250099-630 1 ft.
8 lense, cliplite led 02250129-189 1
9 panel, instrument plastic ssam 02250129-190 1
10 decal, starting aid 185-375 cat 02250130-631 1
11 harness, voltmeter 125-425 jd/cat 02250130-635 1
12 decal, group full gauge (ssam) 02250131-486 1
13 switch, engine ignition 12-volt 02250132-883 1
14 tee, male branch 3/8”tube x 1/4”npt m 02250136-998 1
15 valve, ball 2-way 1/4”npt 02250136-999 1
16 elbow, 90 f 3/8”tube x 1/4”npt 02250137-033 1
17 cover, access ssam molded abs 02250137-265 1
18 controller, ssam 185-60hp 02250139-296 1
19 gauge, temp mech 8ft 140-300$sf 02250143-278 1
20 adapter, red 1/2-14 npt murphy thrd 02250155-384 1
21 harness, wiring 185 (John Deere) TII 02250155-951 1
• harness, wiring 185 (Caterpillar & Perkins) TII 02250155-954 1
22 switch, starter push-button 040038 1
23 screw, tc-f rd hd #6-32 x 1/2 835700-050 2
24 washer, pl-b reg pltd #6 838200-045 2
25 bushing, red pltd 1/4 x 1/8 867100-005 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
