25
Fig.29 shows the Single-phase motor, Single-phase reversible motor (without brake) connection
and the standard specifications.
Fig.29-a In a case of capacitor run type 15W-90W
MC: Electromagnetic
contactor
OLR: Overload relay or
thermal relay
SW: Rotation shifting
switch
These should be
furnished by the
customer.
C: Capacitor Accessory
· For 15W–90W capacitor run type , connect the accessory capacitor. (See Table 7 on page 23
for the capacitor.)
· Do not open water-proof dust-proof box for
water-proof type , otherwise electrical shock, fire
or damage to the equipment may result.
· A capacitor is not water-proofed for
water-proof type .
· This drawing shows for a motor based on standard specification for domestic market. Motor
based on overseas standard shall be referred to us.
100VClass 200VClass
Motor
R
C
MC
OLR
SW
S
BlackWhite Blue
TurntheswitchSWtochangethecurrenttotheoppositedirection.
(Wheninstantswitchingisrequired,useareversiblemotor.)
Motor
R
C
MC
OLR
SW
S
BlackWhite Brown
Operation in one direction
Operating in
both directions
Control panel
Terminal box
Control panel
Terminal box
6. Wiring
