Specification8-
Main Specifications
SH145X-6 SH145XU-6
Basic
Standard bucket capacity (ISO
heaped)
0.50 m
3
0.45 m
3
Operating weight 14500 kg 15300 kg
Engine model ISUZU GJ-4JJ1X
Rated output
70.9 kW/2000 min
-1
Displacement 2999 ml
Dimension
Overall length for transport 7880 mm (standard) 7540 mm (standard)
Overall width for transport 2490 mm 2490 mm
Overall height for transport 2790 mm (standard) 2770 mm (standard)
Overall track length 3500 mm 3500 mm
Overall track width 2490 mm 2490 mm
Standard shoe width 500 mm
Performance
Travel speed: High-speed/low-speed 5.6 km/h/3.4 km/h
Grade ability 70 % (35°)
Swing speed
11.2 min
-1
Bucket digging force: Normal/boosted 90 kN/95 kN (standard) 89.3 kN (standard)
Arm digging force: Normal/boosted 62 kN/66 kN (standard) 59.5 kN (standard)
Hydraulic
equipment
Pump type Double variable displacement piston pump + gear pump
Maximum pressure: Normal/boosted 34.3 MPa/36.3 MPa 34.3 MPa (standard)
Traction motor type Variable displacement piston motor
Parking brake type Mechanical lock
Swing motor type Fixed displacement piston motor
Capacity
Fuel tank capacity 200 L
Hydraulic tank specified capacity 75 L
Hydraulic oil capacity 158 L
* The units shown are international SI units.
