Summer Fun 108023 - Unit Dimensions

7
7. Dimension
E
D
C
FG
A
H
B
※ Above data is subject to modification without notice.
Note: The picture above is the specification diagram of the pool heat pump, for technician’s installation and layout
reference only. The product is subject to adjustment periodically for improvement without further notice.
A B C D E F G H
108023 410 645 404 430 890 250 75 658
108024 410 645 404 430 890 290 75 658
108025 410 645 404 430 970 320 75 658
