Summers ULTIMATE NT - Page 156

SECTION 8 - PARTS
8.83
SECTION 8 - PARTS
CROSS OVER PLUMBING PACKAGE 3" COMMON
9/4/2013
8S9939.iam/
QTY
PN
28A1002 48A1402 18A1412 48A2233 18A2235 18A2256 18A2262 18A2296 18A2331 18A2354 18A4048 18Z0530
8A2331
2" PLUG
8A2233
2" FLNG CLMP
8A1402
GSKT
8A2296
2" FLNG T
8A1402
GSKT
8A2233
2" FLNG CLMP
8A1402
GSKT
8A2233
2" FLNG CLMP
8A2354
2" FLNG BV
8A2233
2" FLNG CLMP
8A1402
GSKT
8A2256
2"X2" HB, E
8A1002
2" HC
8Z0530
MN TANK PMP FILL TAG
8A4048
11" TIE
8A2235
FC 300
8A1412
3" GSKT
8A1002
2" HC
CROSS OVER PLUMBING PACKAGE 3" COMMON
8A4028
(33")
8A2262
90° 2" X 300 FE
MOVE FROM 4 WAY CROSS AND INSTALL ON TOP OF TEE ON CROSS OVER PLUMBING KIT.
TO 3 WAY TEE ON
SUCTION SIDE OF PUMP.
WOULD BE 1ST TEE ON 3"
HOSE COMING FROM TANK.
