SECTION 5 - ELECTRICAL
5.1
THIS SECTION CONTAINS ELECTRICAL DIAGRAMS THAT MAY BE HELPFUL IN THE EVENT OF
A SPRAYER MALFUNCTION. THIS SECTION IS PROVIDED FOR YOUR INFORMATION AND TO
AID SERVICE WHEN DISCUSSING SERVICE PROBLEMS OVER THE PHONE.
NOTE!
OPERATORS INSTALLING FOAM MARKERS ON ULTIMATE SPRAYERS BE ADVISED
THAT LIGHTED SWITCHES INSTALLED IN ELECTRICAL SWITCH BOX WILL CARRY 15
AMPS MAXIMUM. MARKERS EXCEEDING SWITCH AND WIRING CAPACITY WILL NOT
PERFORM EFFICIENTLY ON AN INADEQUATE CURRENT SUPPLY. UNITS WITH A LARGE
CURRENT NEED SHOULD USE WIRING HARNESS SUPPLIED WITH THE MARKER. A
SIMPLE RELAY CIRCUIT COULD ALSO BE USED TO SUPPLY CURRENT THROUGH A 6
GAUGE WIRE AND BE OPERATED WITH THE SUMMERS ELECTRICAL SWITCH BOX.
