Summers ULTIMATE NT - 2.5 TRANSPORTING AND OPERATION OF SPRAYER FROM FIELD TO FIELD

2.23
SECTION 2 - SPRAYER OPERATION
IMPORTANT!
ANALOG GAUGES USED IN RAVEN CONSOLES MAY RETAIN SMALL AMOUNTS OF FLUID IN THEM AND
SHOULD NOT BE SUBJECT TO EXTENDED PERIODS OF FREEZING TEMPERATURES. STORE GAUGE IN-
DOORS AFTER SPRAYER HAS BEEN USED AND BEFORE IT IS EXPOSED TO FREEZING TEMPERATURES.
IMPORTANT!
CERTAIN CHEMICALS AND FERTILIZERS MAY CAUSE PAINT DETERIORATION. TO REDUCE CHANCE OF
SPRAYER PAINT DETERIORATION, CLEAN SURFACES CONTACTED BY CHEMICAL IMMEDIATELY AFTER
USE.
ponents.
2. Spray solution through nozzles.
3. Allow dripless nozzles to drain by loosening each diaphragm check valve nut.
G. When changing chemicals follow chemical manufacturers’ WARNINGS, instructions, and proce-
dures concerning sprayer system cleaning.
2.5 TRANSPORTING AND OPERATION OF SPRAYER FROM FIELD TO FIELD
1. UNFOLD BOOM FROM TRANSPORT TO FIELD POSITION.
CAUTION
REVIEW SECTION 2.1 SPRAYER OPERA-
TION SAFETY BEFORE PROCEEDING
IMPORTANT!
SPRAYER SHOULD BE PARKED ON A LEVEL SURFACE FOR FOLDING AND UNFOLDING
OPERATIONS. OPERATOR MUST BE SURE AREA IS CLEAR OF POWER LINES AND OTHER
OBSTRUCTIONS.
A. Activate vertical height switch on control box and select tractor hydraulics to extend cylinders and
lift booms up out of transport rests.
B. Deactivate vertical height switch.
C. Activate part 1 boom fold switch and select tractor hydraulics to unfold part 1 booms.
D. Deactivate part 1 boom fold switch.
E. Activate right and left tip lift switches and select tractor hydraulics to lower tip lifts.
F. Deactivate tip lift switches.
G. Activate part 2 boom fold switch
and select tractor hydraulics to
unfold part 2 booms
H. Deactivate part 2 boom fold
switch.
NOTE
INNER BOOMS MUST BE COMPLETELY UN-
FOLDED BEFORE UNFOLDING OUTER BOOMS.
ONCE OUTER BOOMS ARE MOVED FROM
TRANSPORT POSITION A SAFETY SWITCH IS
OPENED PREVENTING FURTHER INNER BOOM
MOVEMENT.
