Service Information 13
4.3.1 Load Cell Wiring to Junction Box
The four load cells are each wired to their respective terminals in the junction box according to the corner
numbering system shown in Figure 4-3, and the coloring code in Table 4-2.
Pull excess cable out of the junction box enclosure and tighten the cable grips until snug. Finally, gently pull on
each of the four cables to make sure that they do not slip.
Figure 4-3. Corner Numbering - Top View
Cable Color Code J-Box Terminal
Red +Excitation
Black -Excitation
Green +Signal
White -Signal
Bare or Clear Shield
Table 4-2. Load Cell Wiring
