Summit B41602 - Installing the Cook Top

Page 7
STEP #4
Installing the Cook Top (Figure D below)
There are two mounting brackets supplied with the glass ceramic cook top.
These brackets are designed to hold the cook top firmly in place. The cook top
does not have a metal frame and should be bedded to the countertop using a
soft bedding compound that will prevent damage if later removal for service is
necessary. We recommend a very small bead of silicone sealant.
Attach the two mounting brackets supplied with the cook top (as shown below) to
the inside vertical surface of the cutout. The brackets are to be mounted on
opposing sides. Center the bracket in the opening, flush with the countertop, and
secure with long self-tapping screws that are provided. Position the cook top in
the cutout opening and press firmly on all sides to seal the frame into the bedding
compound. Secure the cook top to the brackets from underneath with the small
sheet metal screws that are supplied.
BE CAREFUL NOT TO OVERTIGHTEN THE SCREWS.
Fig. D
