Summit BIM44GADA - Drain

13
Drain
You must connect the drain line before using the ice maker. Follow the steps below.
There are two types of ice machine modes, one that drains by gravity and one that has an
internal drain pump.
This unit can pump out water up to a rise of 1.5m (59”)
or over a horizontal length of 1.5m (59”).
WATER VALVE
WATER FLTER
POWER
WATER INLET
WATER DRAIN
WATER VALVE
WATER FLTER
POWER
WATER INLET
WATER DRAIN
