Summit CR2110 - Product Specifications

2
Product Specifications
All models have double burners.
CR2110:
120V AC – two 6” (140 mm) burners @ 1200 watts each
CR2220:
220V AC – two 6” (140 mm) burners @ 1200 watts each
Overall dimensions: 11¾” x 19⅝” x 2⅛”
(300 mm x 500 mm x 55,3 mm)
Cutout dimensions: 11⅛” x 19¼”
(282 mm x 490 mm)
WH in the model number suffix indicates model has a white ceramic glass
cooktop. Others are black.
TK15 in the model number suffix indicates that the model includes a Trim
Kit that allows the unit to fit into a 15” wide cutout.
For future reference, please record your cooktop’s Model and
Serial Numbers (on bottom of unit) of here:
Model____________________________________
Serial Number______________________________
