Summit CR2220 - Summary of Cutout Dimensions

7
Summary of Cutout Dimensions
Model Width Depth
CR1115 11⅛" 11⅞"
CR2110, CR2220 11⅛" 19⅛"
CR3240 19⅞"
18⅜"
NOTE: When making the countertop, radius the corner of the cutout (1/4”
radius is typical). This will prevent cracking of the countertop. Follow
manufacturer’s instructions regarding minimum corner radius and
reinforcement of corners.
Model: CR3240
Fig. 4c
