INSTALLATION
Important! This new appliance may only be installed and connected by a registered specialist.
Please observe these instructions; otherwise the warranty will not cover any damage that may
occur.
Appliance dimensions
Width 290mm (11.42”)
Depth 520mm (20.5”)
Height 50mm (2.0”)
Countertop cut-out dimensions
Width 273mm (10.75”)
Depth 505mm (19.9”)
Height 150mm (5.9”)
NOTE: When preparing the countertop, radius the corners of the cutout (1/4” radius is
typical). This will prevent cracking of the countertop. Follow manufacturer’s instructions
regarding minimum corner radius and reinforcement of corners.
