Anti-Tip stability device installation
instructions
1. The anti-tip device has to be attached
to the floor as shown in figure 3.
The dimension for the bracket
location from the floor is determined
after the appliance feet have been
adjusted to the proper installation
height shown in the instructions and
the appliance has been leveled.
2. Locate the anti-tip device on the wall
at the measured dimension from
where the left side of the appliance
(facing range) is to be located.
3. Slide range into place making sure
the anti-tip device is facing the anti-tip
hole on the cooktop and is screwed
into place.
Tip-Over Hazard
A child or adult can tip the range and be
killed. Connect anti-tip bracket to rear
range foot. Reconnect the anti-tip
bracket if the range is moved. Failure to
follow these instructions can result in
death or serious injury to children and
adults.
13
