I T L S E R V I C E M A N U A L
H-8
HYDRAULIC SYSTEM
Ÿ Unscrew allen screw from lift body for removal of
hydraulic cylinder.
Ÿ Remove hydraulic cylinder from lift body.
Step - 4: Removal of Rock Shaft
Ÿ Unlock circlip from both ends of Rock Shaft as shown
in figure.
