I T L S E R V I C E M A N U A L
H-9
HYDRAULIC SYSTEM
Ÿ Remove screw plug from ram arm for removal of
Rock Shaft as shown in figure.
Ÿ Remove the Rock Shaft by using hammer as shown
in figure.
Ÿ Remove lift arms by using hammer as shown in
figure.
