I T L S E R V I C E M A N U A L

H-17

Operation 1: Assembly the plugs and washers on Auxiliary valve

HYDRAULIC SYSTEM

Metallic Plug

Copper Washer

Torque 3-3.5 Kgm

Copper Washer

Domed Cap Nut

Nut

Ÿ Take Out Domed Cap Nut

Ÿ Copper Washers and Nut

Ÿ Assemble the Auxiliary Valve on the Rockshaft
