Summit TX25H - Page 14

I T L S E R V I C E M A N U A L
H-12
H 5.1 HYDRAULIC CIRCUIT DIAGRAM OF MODEL SUMMIT TX25H WITH DOUBLE ACTING DCV
CIRCUIT WITH PRIORITY VALVE UPTO 10.56 GPM
HYDRAULIC SYSTEM
Steering Unit to
Steering Cylinder
Steering Unit
40 CC
Return Pipe
St. Unit to Tank
Tank
Delivery Pipe
P-Valve (CF)
to QRC-2
Hydraulic Lift
Load Sensing
Semi Flexible Pipe
Semi Flexible Pipe
P-Valve to St. Unit
Delivery Pipe
Pump to P-valve
Hydraulic Pump
5.5 CC
Delivery
Port
Suction
Port
Hose Pipe
DCV
Delivery Pipe
P-valve to DCV
Delivery Pipe
DCV to Lift
Strainer
Suction Pipe
With Flange
Delivery Pipe
P-Valve (CF)
to QRC
Priority
Valve
