Sun Gold Power SGR-18K20E User Manual

Sun Gold Power Inc
www.sungoldpower.com
11
7.2.2. Interface Definition
RS232--Using 6P6C vertical RJ11 socket
RJ11
Definition description
2
NC
3
TX
4
RX
5
GND
RS485 and CAN interface
RS485--Using 8P8C vertical RJ45 socket
CAN--Using 8P8C vertical
RJ45 socket
RJ45 Pin
Definition description
RJ45 Pin
Definition
description
1、8
RS485-B1
9、10、11
、14、16
NC
2、7
RS485-A1
12
CANL
3、6
GND
13
CANH
4、5
NC
15
GND
Parallel communication port
RS485--Using 8P8C vertical RJ45
socket
RS485--Using 8P8C vertical RJ45
socket
RJ45Pin
Definition
description
RJ45 Pin
Definition
description
1、8
RS485-B
9、16
RS485-B
2、7
RS485-A
10、15
RS485-A
3、6
GND
11、14
GND
4、5
NC
12、13
NC
