Sun-Mar EXCEL - COMPACT SPECIFICATIONS; COMPACT Explosion Diagram

COMPACT SPECIFICATIONS
COMPACT EXPLOSION DIAGRAM
1) Toilet Seat
2) Bowl Liner
3) Handle Cover
4) Swivel Handle
5) Top
6) Drum Door
7) Bio-drum™
8) Drum Locker
9) Drum Bearing Plate (Front)
10) Left Humus Deflector
11) Drum Locker Thumb Screw
12) Finishing Drawer
13) Rubber U Channel
14) Heater Tray
15) Insulation
16) Heating Element
17) Thermostat
18) Aluminum Sheet
19) Power Box Assembly
20) Safety Drain Assembly
21) Right Humus Deflector
22) Tank
23) Air Intake Vent
24) Large Bio-drum™ Gear
25) SS Shaft
26) Small Gear
27) Fan Assembly
28) Seat Screw
19
Toilet Maximum
Amps
Fan
Power
Heater
Power
Avgerage
Power
COMPACT
(115V)
2.0 A 35 Req 200 W 125 W
COMPACT
(240V)
1.0 A 35 Req 200W 125 W
