Sun-Mar MOBILE - MOBILE; SPACESAVER Specifications

- 20 –
MOBILE / SPACESAVER SPECIFICATIONS
EXPLOSION DIAGRAM & PART NUMBERS
MOBILE SPACESAVER
1 Toilet Seat 11 Drawer 23 Nylon Drive Gear
2 Bowl Liner 12 MOBILE Face Plate 24 Top
3 Front Cover 13 SPACESAVER Heating Tray 25 Shaft Holder
4 Drum Door 14 Heating Element C9806 26 PACESAVER Fan
5 Handle Kit 15 Thermostat 27 Filter Box (MOBILE)
6 Humus Deflector Left 16 Electric Box 28 12 Volt 5.4 Watt Fan(MOBILE)
7 Front Bearing Plate 17 Tank 29 Zeolite Filter (MOBILE)
8 Snap Apart Hinge (MOBILE) 18 1” (25mm) Drain Assembly 30 Carbon Filter (MOBILE)
8 Footrest Channel 19 Drum Screen
9 Drum Locker 20 Humus Deflector Right
10 Folding Footrest (MOBILE) 21 Patented Bio-Drum
10 Footrest (SPACESAVER) 22 Shaft
Electrical Specs MOBILE MOBILE 12V SpaceSaver
Maximum Amps 2.0 8.0 1.2
Fan Watts
(Required) 5 .4 req . 5.4 req. 35req.
Heater Watts 160 90 160
(When on)
Average Power
Use In Watts 85 50 110
(Heater on
½ time)
MOBILE/SPACESAVER MOBILE 12 VOLT
