Full-load operation without any drop in capacity within the range of working
environment temperature
Extensive electronic protection
1.2 Characteristics
❶
SELECT button
❻
RS485 communicationinterface
❷
RTS
★
Interface
❼
Mounting Hole Φ5mm
❸
PV Terminals
❽
ENTER button
❹
Battery Terminals
❾
LCD
❺
Load Terminals
★If the temperature sensor is short-circuited or damaged, the controller will
charge or discharge at the default temperature setting of 25 ºC.
1.4 Maximum Power Point Tracking Technology
Due to the nonlinear characteristics of solar array, there is a maximum energy output
point (Max Power Point) on its curve. Traditional controllers, with switch charging
technology and PWM charging technology, can’t charge the battery at the maximum
power point, so can’t harvest the maximum energy available from PV array, but the
Figure 1 Product Characteristics
