100V~250V
Data in
Router
Non-PoE
ELE (Force Electricity)
Wiring method:
≥18 wire gauge
DC 12V
Power Adapter
For Non-PoE Application (if you extend the power):
The camera may not work properly if the power reaches the camera is below
12V due to resistance along the extended DC line (distance dependent). If that
happens, please make your AC power source near the camera, and connect it
with our default adapter you received from the package.
For extension, you can select from AC power extension cable (no distance limit)
or thick (≥18 AWG) DC power extension cable.
Risk Relevant
1.Using 24VAC or higher voltage adapter (16V, 24V) will immediately dam-
-age the camera and void the warranty.
2.The camera will be exposed to high risks of motherboard damage and
void the warranty if you use passive PoE injector/splitter.
AC110-220V in
RJ45 in
48V 0.5A DC out
PoE (cat5/5e/6)
DC12V out
RJ45 out
Active
PoE injector
Active
PoE splitter
Active PoE Injector/Splitter are allowed if you use PoE to power non-PoE camera.
- 10 -
Wiring Type B: Non-PoE (DC12V) Solution
