INSTALLATION KIT
You may not need all parts in this kit. Discard any unused parts.
Part Specifi cations Quantity
Tapered Spacer Blocks 17” 2
Centering/Support Blocks 4.5” x 3.5” x 1.5” 2
Plastic Divider 1/8” x 4.5” x 14.5” 1
Stuffer Seal 1” x 1.5” x 84” 1
Seal 1.5” x 1.5” x 14” 2
Seal 1.5” x 1.5” x 26.5” 2
Seal 1.5” x 1.5” x 14” 2
Seal 1.5” x 3/8” x 26.5” 2
Seal 1.5” x 3/8” x 14” 1
Seal 1” x 3/4” x 14” 2
Trim Frame (side legs) 2
Trim Frame (top and bottom legs) 1
Ground Wire (green) 1
Nut for Grounding Screw 1
Grille (plastic) 1
Nuts (plastic) 4
Screw with Washer 4
PRE-INSTALLATION
If you are installing your air conditioner into an existing sleeve and there is an existing rear grille, the
louvers will have to be bent as per the instructions at the beginning of each section. If this does not
work,
Remove the existing grille.
Place the included aluminum grille towards the rear of the unit.
Mark through the hole positions.
Drill through the sleeve fl anges with an 1/8” drill bit.
Attach the new grille with the self-threading screws and washers (not included).
It is very important that the partition be placed on the left side of the sleeve.
OR
Remove the existing grille.
Use the included plastic grille and secure to sleeve fl anges using the existing screws and washers.
1.
2.
3.
4.
5.
1.
2.
