8.4 PRE-MOUNTED CABLES AND CONNECTORS
Mounting Configuration Pre-mounted cables Pre-mounted connectors
Type TUV – PV1-F & UL – PV wire locking polarized connectors
Cross section 4.0 mm² 4 mm dia.
Max. current 30 A at 85°C IEC 25 A and UL 20 A
Max. system voltage IEC 1000 V DC/ UL 1000 V IEC 1000 V DC/ UL 1000 V
Temperature rating -40°C to +90°C -40°C to +85°C
Qualification TUV 2PFG & UL PV wire EN 50521 & UL for PV sys
Module Model Number Connector Type
SE-MxxxByC-3w S418 BizLink PV Connector
SE-MxxxByC-3z Amphenol Helios H4 PV Connector
SE-DxxxByC-3w S418 BizLink PV Connector
SE-DxxxByC-3z Amphenol Helios H4 PV Connector
SE-FxxxByC-3w S418 BizLink PV Connector
SE-FxxxByC-3z Amphenol Helios H4 PV Connector
