Sunfire SF80 - Specifications; For the; Operating Temperature Range

10
+1 (855) 251-1649
sunfireheaters.com
*Fuel-temperature considerations are necessary when operating in sub-freezing temperatures. See
product manual sections NORMAL OPERATION and OPTIONAL ACCESSORIES for more information.
min. 3’
(0.91 m)
min. 3’
(0.91 m)
min. 7’
(2.13 m)
27.75”
70.5 cm
19.75”
50.2 cm
26”
66.1 cm
FUEL REQUIREMENT:
Diesel, No. 2 Heating Oil, Kerosene
FUEL INPUT:
0.58 gal/h Diesel; 0.56 gal/h Kerosene
FUEL TANK CAPACITY:
6 U.S. gallons (22.7 L)
ELECTRICAL REQUIREMENT:
0.5A, 120V / 60Hz 1-Phase
WEIGHT:
Tank empty: 85 lbs (38.6 kg); Tank full: 127 lbs (57.6 kg)
DIMENSIONS:
L: 26” (66.1cm) W: 19.75” (50.2 cm) H: 27.75” (70.5 cm)
OPERATING TEMPERATURE RANGE*:
-20°F (-28.9°C) to 80°F (26.7°C)
MINIMUM CLEARANCE TO COMBUSTIBLE MATERIAL:
Front: 84” (213 cm)
Left/Right Side: 36” (91 cm)
Back: N/A Below: For use on non-combustible flooring
or with heat-rejecting mat
FOR THE SF-80:
Specifications:
