PACKAGE CONTENTS:
1. Heater Assembly
2. Lower Support Frame Leg Assembly
3. Lower Support Frame Axle Assembly
4. Dome Guard
5. Dome Visor
6. Optional Lifting Bracket
7. Optional Lifting Bracket Retainer x2
8. Leveling Foot x2
9. Foot-Adjustment Wrench
10. Wheel x2
11. Axle Cap x2
12. 1/4”-20 tpi x 1-1/2” Frame-Mount Bolts x4 (not
shown)
13. 1/4”-20 tpi x 3/4” Lifting-Bracket Bolts x2 (not
shown)
14. 1/4” Flat Washer x6 (not shown)
15. 1/4” Locking Washer x6 (not shown)
16. 1/4” Nut x6 (not shown)
17. #10 x 1/2” Visor Screw x6 (not shown)
18. Spare Parts (not shown)
19. Thermostat-connection Whip (not shown)
20. Operation & Service Manual (this booklet)
Please review the package contents and ensure that all materials are present. If you find something is missing, contact
SunFire for assistance. DO NOT RETURN THE HEATER TO THE STORE where it was purchased.
1.
2.
3.
4.
5.
6.
11.
x2
9.
10.
x2
8.
x2
Not to scale
7.
x2
FOR THE SF-80:
FOR THE SF-120:
The SunFire SF-80 is shipped preassembled and ready for NORMAL OPERATION. No assembly is required,
though adjustment of the levelling feet may be needed. To adjust the foot, loosen the locking nut on the
threaded foot post and rotate the foot to adjust the height. Tighten the locking nut when finished.
Getting Started:
