Sunfire X24 - Page 15

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 15
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
36" SINGLE STANDARD OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
36 F299 Bolt 1/4-20x1/2" Bell Crank 2
37 4522818 Bell Crank Support Bracket 2
38 4512250 Oven Door Spring 2 C
39 4523497 Oven Door J-Bolt, 6” (F598) 1
40 4526109 Door Spring Adjustment Bracket (26W Door) 1
41 4522770 Kick Panel 26W 1
42
4525442 Knob Assembly - Sunre Oven SIT, deg. F 1 C
4525443 Knob Assembly - Sunre Oven SIT, deg. C 1 C
43 4523081 ES Shield Mount 1
44 4523006 SIT Oven Control 1 C
45 1095499 Straight Connector 7/16 2
46 4523079 ES Shield Rt 1
47 4523080 SIT Lt Shield 1
48 4523499 SIT Top Shield 1
49 4523145 Tube - Sit To Manifold 1
49A 4520720
7/16" Flexible Tubing Sit To Manifold
Note: Applicable Only to Models with 12" Griddles
Mounted on the L/H Side of the Range.
1
50 4522412 Rack Guide, R/H, Sunre 1
51 4522409 Oven Rack 26W x 22D 1
52 4522754 Rack Guide, L/H, Sunre 1
55 4522766 Corner Column R/H 36" 1
56 4522765 Corner Column L/H 36" 1
57 F298N
Bolt, #10-24 x 3/8" Shoulder Truss HD, Nickel Plated
(was F298)
2
58
4523088
36” Valve Panel
All Burners or 12” Griddle on L/H or R/H
Note: Used from (serial#) 0911100101162.
(4523330 is obsolete, used up to 1-Dec/09)
1 2DEC/09
4523615
36” Valve Panel - 24" Griddle on L/H
Note: Used from (serial#) 0911100101162.
(4523633 is obsolete, used up to 1-Dec/09)
1 2DEC/09
4523613
36” Valve Panel - 24” Griddle on R/H
Note: Used from (serial#) 0911100101162.
(4523622 is obsolete, used up to 1-Dec/09)
1 2DEC/09
4524094
36” Valve Panel - 36” Griddle
Note: Used from (serial#) 0911100101162.
(4523622 is obsolete, used up to 1-Dec/09)
1 2DEC/09
58A 4523746 2.5” Valve Panel Hole Cover (Storage Base Option)
59 4523253 36" Plate Rail, Sunre 1
60 4527427
Valve Panel End Cap - Left (was 4523251)
Note: Used from (serial#) 0911100100549 (model) X60-
6R24RR-0003.
1 17NOV/09
61 4527426
Valve Panel End Cap - Right (was 4523250)
Note: Used from (serial#) 0911100100549 (model) X60-
6R24RR-0003.
1 17NOV/09
62 4526110 Burner Box Filler (was 4523193) 2
63 4522562 Manifold Assembly - 36" (without Fittings) 1 C
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
