U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 16
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
36" SINGLE STANDARD OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
64
2127502 Regulator - Natural Gas 4.5" WC 1 C
2127500 Regulator - Propane Gas 10" WC 1 C
65 4529768 90 deg Elbow Fitting,7/16CC to 3/8NPT (was G02352-1) 1
66 G022511 Pressure Test Spigot 1
67 2203400 1/8" NPT Pipe Plug 2
68 4523570 .187 (3/16) Dia Tubing - SIT Valve to Oven Pilot 1
68A 4527220 SIT Pilot Tube Connection 1
69 4523143 .437 (7/16) Dia Tubing - SIT Valve to Oven Orice Fitting 1
70 4522774 Air Shield Pilot 26W 1
71 4522773 Air Shield Solid 26W 1
72 4523031 Capillary Guard 26W Standard Oven 1
73 4523030 Bulb Guard Standard Oven 1
74 4523194 Rail Support Bracket 1
75 1082700 Harness Ring, Nickel Plated 2
76 4522400 Trunion Bracket 2
77 4523087 Grate Support Rail 2
78 4523069 Drip Angle, Large 2
89 4525043
Hearth Support, L/H 36” (removable)
Note: Used FROM (serial#) 0804100101527 (model)
X60-10RR.
1 1MAY/08
90 4525044
Hearth Support, R/H 36” (removable)
Note: Used FROM (serial#) 0804100101527 (model)
X60-10RR.
1 1MAY/08
91 4523032 Fireplate, 26W Oven, Sunre 1
92 4522385 Oven Hearth 26W x 22D - Enamelled 1
95 F16
SIT to Manifold Mounting Bolts (#10-24 x 2-1/2", Round
Head, Slot Drive)
2
96 F312
SIT to Manifold Mounting Lock Nut (#10-24, K-Lock
Nut)
2
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
