Sunfire X24 - Page 17

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 17
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
36" SINGLE STANDARD OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
LEGS & CASTERS
200 4522416 6" Adjustable Leg, Sunre 4
201 4524104 6" Flanged Leg (Optional) 4
202 4526324
6" Caster Package, non-adjustable (Optional)
Note: Includes items 204, 205, 208, and installation
instructions.
1
203 4526323
6" Caster Package, adjustable (Optional)
Note: Includes items 206, 207, 208, and installation
instructions.
1
204 4522417 6" Caster No Brake, 3/4-10 mount, non-adjustable 2
205 4522916 6" Caster With Brake, 3/4-10 mount, non-adjustable 2
206 4525597 6" Caster No Brake, 3/4-10 mount, adjustable 2
207 4525598 6" Caster With Brake, 3/4-10 mount, adjustable 2
208 4526157
Caster Washer
Note: Used FROM (serial#) 0901100100838 (date) 20-
Jan-09.
4 20JAN/09
209 4526325 Caster Washer Kit 1
DOOR COMPONENTS  36" STORAGE BASE MODEL
300 4524282 Door Panel Outer - 36", Standard Base 1
301 4524283 Door Panel Inner - 36", Standard Base 1
302 F557 5/32" Rivet - S/S (Grip Range .039" - .118") 10
303 0780565 Flange Bearing/Bushing 2
304 2530900 0.375" Hole Plug 2
305 3031900 Storage Door Handle 1
306 4524288 Door Hinge Assembly - Right 1
307 4524287 Door Hinge Assembly - Left 1
308 4524284 Door Stop - 36" Door, Standard Base 1
309 F60 Screw-10AX 5/8 InterLock Quad Pan 8
310 0781741 Magnetic Door Catch 1
311* 4523669 Logo, Stick-On, Sunre 1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
